Design Office

Development and design of progression tooling up to 1 800 mm length, Assembly fixtures, Control jigs production fixtures to fit customers needs.

Our skilled designers use 7 CAD work stations using:

  • Autodesk Inventor
  • Vero VISI
  • Autodesk Mechanical Desktop
  • Pro/ENGINEER (external)

VISI Blank as well as VISI Analysis is used to evaluate the behaviour of parts during the stamping processes.

Supported CAD formats: DXF, STEP, SAT (ACIS), IGES, VDA, SET, NEU, CT, STL, VRL, ASC, Catia  V4 a V5, Solid Edge, Solidworks, Unigraphics, Parasolid

CAD software

Autodesk Inventor



Control fixture Assembly fixture
Semi-automatic assembly unit
Tool



Vero Visi

Control fixture
Progress tool
Progress tool


Autodesk Mechanical Desktop

Control jig
Tool



Pro/ENGINEER (external)

Press fixture
Control fixture
Tool
